- 5 -
Electrical, Mechanical
and Thermal Properties
Note: The following technical information and data should be considered representative
or typical only and should not be used for specification purposes.
3M™ Adhesive 200MP
2 mil 5 mil
(3M™ Adhesive Transfer (3M™ Adhesive Transfer
Property
Tape 467MPR was tested) Tape 468MPR was tested)
Insulation Resistance (test voltage = 100 VDC) >1 x 10
10
ohms >1 x 10
10
ohms
Mil-I-46058C
Dielectric Strength – (500 vac, rms [60 hz/sec]) 880 volts/mil 600 volts/mil
ASTM D149-92
Breakdown Voltage 1,760 volts 3,000 volts
Dielectric Constant (at 1 KHz) 3.40 4.06
ASTM D 150-92
Dissipation Factor 0.021 0.022
Tensile Lap Shear – Peak Load 55 lbs.
ASTM D1002-72
(0.5 square inch on #6061 aluminum)
Tensile Lap Shear – Peak Stress 109 PSI
ASTM D1002-72
Tensile Strength and Elongation 51 PSI
ASTM D2370-82 1915%
Thermal Conductivity 0.098 BTU-ft/ 0.101 BTU-ft/
(ASTM C 518, results listed are at 109°F) ft
2
-hr-F ft
2
-hr-F
0.17 watt/m-K 0.18 watt/m-K
Coefficient of Thermal Expansion - first heat 28 x 10
-5
m/m/C -6 x 10
-5
m/m/C
ASTM D 696 - second heat 72 x 10
-5
m/m/C 92 x 10
-5
m/m/C
Specifications
Please specify 3M adhesive 200MP, 2 mil or 5 mil rather than the exact product
number based on the liner configuration. The converter will select the product with
the necessary liner configuration to meet the delivery requirements.
3M adhesive 200MP
2 mil 5 mil
Coat weight
7
(grains/4" x 6") 14 ± 12% 32 ± 12%
(grams/ft
2
) 5.4 ± 12% 12.4 ± 12%
Face Adhesion
8
(exposed side) 30 minimum 37 minimum
ounces/inch
Back Adhesion
8
(liner side) 30 minimum 37 minimum
ounces/inch
7
The amount of adhesive supplied, for pressure-sensitive adhesives, is controlled by the
adhesive coat weight, not the adhesive caliper. Pressure-sensitive adhesives are
compressible which results in high error for caliper measurements. The caliper listed in the
Constructions section (page 1) has been calculated using a density of 1.012 g/cc (testing
caliper is not part of the standard release testing because of the error described.)
8
ASTM D3330, 15 minute dwell on stainless steel. For this adhesive family, the adhesion will be
much higher with longer dwells on stainless steel and other high surface energy materials
(please refer to the typical Physical Properties section in this document to see performance on
other materials after longer dwells).
3M
™
High Performance Adhesive Transfer Tapes with Adhesive 200MP
467MP • 468MP • 467MPF • 468MPF • 467MPR • 468MPR • 7952MP • 7955MP
7962MP • 7965MP • 9172MP • 9172PT • 9185MP • 9188 • 9667MP • 9668MP • 9676
